Features
Constructed with SUS304 stainless steel, it boasts an aesthetically pleasing appearance, outstanding durability and resistance to acid-alkali solutions, with a designed service life of 15 years.
Powered by compressed air instead of electricity, it eliminates potential safety hazards caused by electric sparks.
Features user-friendly one-key operation, which completes the entire cleaning and drying process in one go.
The specially designed spray rod and nozzles ensure thorough cleaning and consistent stencil tension.
Equipped with liquid filling and draining functions.
The cleaning solution is automatically recycled and filtered, resulting in low consumption.
Incorporates an interlocked safety door design that stops operation immediately when opened, ensuring operational safety.
Comes with a high-precision 1μm filtration system to enable long-term recycling of the cleaning liquid.
Adopts components from world-renowned brands to guarantee the machine’s long-term stable operation.
Modular design allows for convenient inspection and maintenance.
Specification document
| Item | Technical Specifications |
| Stencil Size | L736 x W734 x H40 mm |
| Tank Capacity | 40L |
| Washing Time | 3 ~ 5 min |
| Drying Time | 3 ~ 5 min |
| Air Pressure Requirement | 0.5 ~ 0.7 Mpa, 400 ~ 600 L/min |
| Washing/Drying Method | 360° rotating spray cleaning / high-pressure air jet drying |
| Filtration System | 3-stage filtration (1mm / 50µm / 1µm) |
| Machine Dimensions | L800 x W950 x H1650 mm |
| Machine Weight | 230 KG |
