This BC310GLD80M filter bag is a customized dedicated filtration spare part for SMT pneumatic stencil cleaning machines. It is designed to intercept fine impurities, residues and contaminants in the cleaning fluid efficiently, preventing clogging of pipelines, nozzles and pumps inside the equipment. With customizable specifications to match different filter barrels, it ensures stable filtration performance, maintains clean circulating fluid and prolongs the service life of core components of the stencil cleaning machine.
SMT Pneumatic Stencil Cleaning Machine Spare Parts List
| No. | Part Number | Item Name | Specification&Model | Qty | Replacement cycle |
| 1 | BC310MMFT | Door seal strip | Fluorine rubber | 3 meters | 1 year |
| 2 | BC310GLX101 | Filter element | 10 inch 1 micron | 3 of them | 1-2 weeks |
| 3 | BC310GLTMFQ3X | O‑ring for filter barrel | Fluorine rubber | 1 item | 6 months to 1 year |
| 4 | BC310JSQ | Timer | 999S | 2 of them | 1 year |
| 5 | BC310QKF | Pneumatic control valve | 4A310-08/10 | 4 of them | 1 year |
| 6 | BC310GLTYF | Air inlet pressure regulating valve | AW4000-04 | 1 piece | 1 year |
| 7 | BC310YLB | Pressure gauge | Φ40 | 2 of them | 1 year |
| 8 | BC310JZF | Angle seat valve | DN15 | 2 of them | 1 year |
| 9 | BC310GMB1C | Diaphragm pump | 1 inch | 1 piece | 1 year |
| 10 | BC310GLD80M | Filter bag | Customized | 1 piece | 1 year |
| 11 | BC310TCZC | Ceramic bearing | 7005 | 4 of them | 1 year |
| 12 | BC310QDF | Start valve / Emergency stop valve | ER/EP | 1 piece | 1 year |
